LCD-24 - Special Edition Planar Magnetic Headphone with Travel Case (15 Ohm)
![]() |
From Audeze
Availability: Item is currently available.
68,772 Points
See more in Electronics
See more in Audio & Video
Product Description
The special edition Audeze LCD-24 combine technology from the flagship LCD4 with a tuning reminiscent of the highly regarded LCD2, which delivers a robust and refined sound featuring the vibrant midrange, powerful bass, and treble extension iconic to Audeze's flagship headphones. Designed for reference and personal Hi-Fi listening, the LCD24 only require 15 Ohms, allowing them to be easily driven from lower-output devices such as phones, tablets, portable players, or computers. The LCD-24 have been redesigned to make them lighter than the LCD4z, making even more comfortable for long listening sessions.
Instead of utilizing traditional dynamic cone drivers, the LCD-24 implement nano-grade uniforce diaphragms and Double Fluxor magnet arrays for a powerful magnetic flux density. The headphones deliver a frequency response of 5 Hz to 50 kHz with a THD of less than 0.1% and an efficiency of 96 dB per 1 mW. Additionally, the suspension-type carbon fiber and leather headband ensure a comfortable fit. The benefits of a magnetic planar design include faster transient response due to the lighter diaphragm, a wide frequency with low distortion, better heat dissipation, fewer moving parts for greater durability, and better amplifier compatibility because the circuit functions as an almost entirely resistive load.
The headphones also implement the company's patented Fazor technology to guide and manage the flow of sound for better clarity, phasing, 3D imaging, and frequency response. The magnetic structure creates a uniform magnetic field across the diaphragm, without the need for additional ferromagnetic material traditionally found in other planar headphones to remove magnetic interference, reduce harmonic distortion, and lower overall weight. The headphones come with a professional travel case as well as a premium 1/4" to dual 4-pin mini-XLR headphone cable. They are handcrafted in the USA.
Instead of utilizing traditional dynamic cone drivers, the LCD-24 implement nano-grade uniforce diaphragms and Double Fluxor magnet arrays for a powerful magnetic flux density. The headphones deliver a frequency response of 5 Hz to 50 kHz with a THD of less than 0.1% and an efficiency of 96 dB per 1 mW. Additionally, the suspension-type carbon fiber and leather headband ensure a comfortable fit. The benefits of a magnetic planar design include faster transient response due to the lighter diaphragm, a wide frequency with low distortion, better heat dissipation, fewer moving parts for greater durability, and better amplifier compatibility because the circuit functions as an almost entirely resistive load.
The headphones also implement the company's patented Fazor technology to guide and manage the flow of sound for better clarity, phasing, 3D imaging, and frequency response. The magnetic structure creates a uniform magnetic field across the diaphragm, without the need for additional ferromagnetic material traditionally found in other planar headphones to remove magnetic interference, reduce harmonic distortion, and lower overall weight. The headphones come with a professional travel case as well as a premium 1/4" to dual 4-pin mini-XLR headphone cable. They are handcrafted in the USA.
| Number of Included Headphones/Receivers | |
| Number of Included Transmitters | |
| Number of Included Headsets | |
| Number of Included Transceivers | |
| Headphone | |
| Earpiece Design | Over-Ear (Circumaural), Open-Back |
| Earpiece Connection / Wearing Style | Headband |
| Number of Earpieces | |
| Sound Field | |
| Earpad Size | |
| Driver Type | Planar |
| Number of Drivers | |
| Driver Size | 4.17" / 106 mm |
| Diaphragm | |
| Magnet Type | Neodymium |
| Voice Coil | |
| Impedance | 15 Ohms |
| Active Noise Cancellation | No |
| Controls/Microphone Location | |
| Full Remote OS Support | |
| Sensors | |
| Foldable | No |
| Contact Pressure | |
| Performance | |
| Frequency Response | 5 Hz to 50 kHz (Wired) |
| Resonant Frequency | |
| Sensitivity | 96 dB/mW |
| Matching Tolerance | 1 dB |
| Maximum Sound Pressure Level (SPL) | 130 dB |
| Maximum Power Handling | 5000 mW |
| Output Power | 250 mW |
| Volume Limiting | |
| Noise Attenuation | |
| Total Harmonic Distortion (THD) | 0.1% |
| SNR | |
| CMRR | |
| Channel Separation | |
| Storage Capacity | |
| Number of Mics | |
| Beamforming Support | |
| Type | |
| Diaphragm Size | |
| Mic Boom Location | |
| Pickup Pattern | |
| Frequency Response | |
| Operating Voltage | |
| Sensitivity | |
| Maximum SPL | |
| Impedance | |
| SNR | |
| Distortion | |
| Equivalent Noise Level | |
| Wireless Transmission | |
| Number of RF Channels | |
| RF Bandwidth | |
| Max Systems per Setup | |
| Modulation | |
| DECT Standard | |
| Duplex Mode | |
| RF Channel Access Method | |
| Latency | |
| Speech Encoding | |
| Transmission Speed | |
| Approximate RF Sensitivity | |
| Supported Audio Codecs | |
| Bluetooth Profiles | |
| Bluetooth | |
| Bluetooth Power Class | |
| Wireless Range | |
| Frequency | |
| Transmitter Power | |
| Multipoint Support | |
| Maximum Paired Devices | |
| Bluetooth Transmitter Modulation | |
| NFC | |
| Wireless Chipset | |
| True Wireless Pairing Method | |
| Transmitter Host Connection | |
| Encryption | |
| Wired Connectivity | |
| Audio Connector to Source | 1 x 1/4" TRS Male Straight |
| Connector Plating | Silver |
| Adapter (Included) | |
| Cable Design | Y-Type |
| Audio Connector to Earpiece | 2 x Mini XLR 4-Pin Female |
| Cable Length | 6.23' / 1.9 m |
| Cable Length | |
| Cable Color | |
| Cable Conductor Material | Oxygen-Free Copper |
| Battery Type | |
| Battery Type | |
| Battery Chemistry | |
| Battery Chemistry | |
| Capacity (mAh) | |
| Runtime | |
| Runtime | |
| Quick Charging Times | |
| Recharge Time | |
| DC Input Power | |
| Charging Port | |
| Charging Cable Length | |
| Number of Channels | |
| Users per System | |
| I/O Connectors | |
| Antenna | |
| Audio Decoding | |
| Number of Charging Ports | |
| AC/DC Power Adapter | |
| AC Input Power | |
| Power Consumption | |
| Additional Runtime | |
| Battery Chemistry | |
| Capacity | |
| Charging Time | |
| Charging Interface | |
| Platform Support | |
| OS Compatibility | |
| Required Hardware | |
| Internet Connection | |
| Charging Temperature | |
| Operating Temperature | |
| Storage Temperature | |
| Operating Humidity | |
| Storage Humidity | |
| Certifications | |
| Physical | |
| Water Resistance | |
| IP Rating | |
| LED Indicator | |
| Material of Construction | |
| Dimensions | |
| Weight | 19 oz / 540 g (without Cable) |
| Warranty Length | Limited 3-Year Warranty |
