Product Description
The StudioBook features the ScreenPad 2.0. While you can use it as a traditional touchpad, the ScreenPad 2.0 can become an interactive secondary touchscreen. The intuitive interface may resemble a smartphone, but it allows you to easily manage tasks and create your own seamless multitasking workflow. ASUS provides a variety of utility apps you can use, such as Quick Key, which allows for one-tap automation of complex keystrokes, Handwriting, Number Key, and Office Xpert. There are also quick controls available on the ScreenPad 2.0, like the ability to launch a video or group chat, freeing up your main 17" display for an uninterrupted, clutter-free workflow.
Windows 10 Pro for Workstations (64-bit) scales up for machines with a high number of logical processors and large amounts of RAM for server-grade hardware and power users. It also includes all of the features of Windows 10 Home plus many designed specifically for business users, including Hyper-V virtualization, BitLocker disk encryption, and remote desktop access. Devices will also be able to join domains and the Azure Active Directory, and they can even access a specialized version of the Windows Store featuring custom, company-specific applications.
| Operating System | Windows 10 Pro for Workstations |
| Performance | |
| CPU Architecture | x86 |
| Chipset | |
| CPU Socket | |
| CPU | 2.8 GHz Intel Xeon E-2276M 6-Core |
| CPU | |
| Maximum Boost Speed | 4.7 GHz |
| L3 Cache | 12 MB |
| Memory Type | DDR4 |
| Total Installed Memory | 64 GB |
| Memory Configuration | 4 x 16 GB |
| Maximum Memory Capacity | 128 GB |
| Memory Slot Type | |
| Memory Slots | 4 (0 Available) |
| Buffered Memory | |
| ECC Memory | |
| Intel Optane Memory | |
| Graphics Type | Dedicated |
| GPU | NVIDIA Quadro RTX 5000 with 16 GB GDDR6 VRAM |
| Afterburner | |
| Display | |
| Panel Type | Unspecified LCD |
| Size | 17" |
| Aspect Ratio | 16:10 |
| Resolution | 1920 x 1200 |
| Touchscreen | No |
| Finish | Matte |
| Maximum Brightness | |
| Color Gamut | 97% DCI-P3 |
| Refresh Rate | |
| Contrast Ratio | |
| Response Time | |
| Adaptive-Sync Technology | |
| Viewing Angle (H x V) | 178 x 178° |
| Storage and Expansion | |
| Total Drive Bays | |
| 2.5" Slots | |
| SSD Slots | 2 x M.2 PCIe x4 (In Use) |
| Total Installed Capacity | 4 TB |
| Solid State Storage | 2 x 2 TB M.2 NVMe PCIe |
| Hard Disk Storage | |
| Hybrid Storage | |
| MPX Bays | |
| PCI Expansion | |
| PCI Expansion in MPX Bays | |
| Expansion Slots | |
| Optical Drive | None |
| I/O | |
| Ports | 3 x USB Type-A (USB 3.1 / USB 3.2 Gen 2) |
| USB Type-C Ports | 2 x Thunderbolt 3 (Supports DisplayPort) |
| Display | 1 x HDMI 2.0 |
| Audio | 1 x 1/8" / 3.5 mm Headphone/Microphone Input/Output |
| Built-In Speakers | Yes |
| Built-In Microphones | Yes |
| Media Card Slots | 1 x SD (Unspecified Type) (UHS-II [312 MB/s]) |
| Communications | |
| Ethernet | 1 x RJ45 (Gigabit) |
| Wi-Fi | Wi-Fi 6 (802.11ax) |
| MU-MIMO Support | 2 x 2 |
| Bluetooth | 5.0 |
| SIM Card Size | |
| GSM 3G/3.5G | |
| 4G LTE | |
| GPS | Optional |
| NFC | No |
| Webcam | User-Facing: 720p |
| Battery | |
| Battery Chemistry | Lithium-Ion Polymer (LiPo) |
| Capacity | 95 Wh |
| Maximum Runtime | |
| Keyboard & Mouse | |
| Keyboard | Notebook Keyboard with Number Pad |
| Pointing Device | TouchPad |
| General | |
| Security | Kensington Lock Slot, Fingerprint Reader |
| Power Supply | 280 W |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Operating Temperature | |
| Operating Humidity | |
| Mounting-Hole Pattern | |
| Dimensions | 15.03 x 10.43 x 1.11" / 38.18 x 26.49 x 2.82 cm |
| Weight | 5.5 lb / 2.49 kg |
| Warranty Length | Limited 3-Year Warranty |
